JDrafting is an open source Java application to create Technical Drawing exercises.
This application is inspired by the 'Classical Construction', also known as 'Ruler-and-compass Construction' or 'Compass-and-straightedge construction'. However, another drawing tools can be used.
(More info about classical construction: https://en.wikipedia.org/w/index.php?title=Compass-and-straightedge_construction)
Download examples in 'Files tab'
JRE 8+ needed
Github:
https://github.com/miguelalejandromorenobarrientos/jdrafting
Features
- See exercise step by step
- Easy to use
- Export to SVG/PNG
- English/Spanish/Greek
- Basic shapes; points, segments, arcs, circumferences, ...
- Ruler and protractor
- Other shapes; rectangles, polygons, polylines, splines, free hand, text box, math functions
- Tools; perpendiculars, parallels, mediatrix, midpoint, bisectrix, capable arc, ...
- Transform; rotations, translations, homothety, symmetries, ...
Audience
Education, Engineering
User interface
Java Swing
Programming Language
Java
