Mod FreeCAD-PCB allow you to import PCB boards to FreeCAD.

Scope of mod:
- support for many different layers,
- possible to choose colours, transparency and names for each layer,
- mod allows you to import IGES models with colours,
- possible to show holes/vias independent.

Moduł FreeCAD-PCB pozwala na importowanie płytek PCB do programu FreeCAD.

Możliwości modułu:
- wsparcie dla wielu różnych warstw,
- wyświetlanie otworów, przelotek niezależnie od siebie,
- możliwość wyboru koloru, przeźroczystości oraz nazwy dla poszczególnych warstw,
- importowanie modeli zapisanych w formacie IGS wraz z kolorami.


Supported software:
- Eagle (*.brd)
- Razen (*.rzp)
- FreePCB (*.fpc)
- gEDA (*.pcb)
- FidoCadJ (*.fcd)
- KiCad (*.kicad_pcb)
- IDF v2/v3

Requirements: FreeCAD >= 0.14

Project forum: https://sourceforge.net/p/eaglepcb2freecad/forum/
